Innovative Design, 80MM Rafale RC EDF Jet
FMS 80mm Rafale features an attractive trim scheme, excellent scale details and fully functional canards- allowing the aircraft to be truly unique when compared to other 80mm EDF aircraft. Details such as the pilot, cockpit interior, panels, removable armaments, auxiliary fuel tanks, refueling probe, targeting sensor etc; dynamic features such as functional LED navigation and landing lights, CNC shock-absorbing electric retracts, functional canards and flaps etc.
Utilising screws, latches and quick connectors, experienced builders can complete the build process in as little as 5 minutes.
Functions such as delta-mixing, sequential landing gear bay doors, alternating flash navigation lights, nose gear landing lights, slowed flaps etc are all controlled by a central control board. An 80mm 12 bladed EDF with a platinum edition 3280 inrunner motor and 100A high performance ESC easily accomplishes fighter jets maneuvers with realistic sound and speed.
What's in Box
- 80mm EDF with 12 bladed fan
- 3280-2100KV Brushless Motor (installed)
- Hobbywing 100A ESC (installed)
- 13g Digital All-metal Servos (installed)
- CNC All-metal Landing Gear (installed)
- Flashing Navigation Lights On Wings And Taxi Tights On the Bottom Of the Fuselage (installed)
- Attractive Red-gray Decal
- Product Manual
Need to Complete
Transmitter
6+ channel Receiver
22.2V4000mAh-5000mAh 45c (recmmanded)
Compatible Charger
Notes to buyers:
RTF (Ready to Fly) airplanes come with everything you need to fly in the box. A transmitter, receiver, battery, charger, and all other required electronics are included and pre-installed from the factory.
PNP (Plug-and-Play) airplanes include the ESC, motor, and servos all pre-installed from the factory. Transmitter, receiver, battery, and charger are not included.
Specification
| Wingspan | 974mm /38.3 in |
| Overall Length | 1409mm /55.5 in |
| Flying Weight | Around 3280g |
| Motor Size | 3280 KV2100 |
| ESC | 100A |
| Servo | 13gX7pcs |
| Radio | 6CH Channel |
| CG (center of gravity) | 110-130mm |
| Prop Size | 80mm Ducted Fan 12-blade |
| Recommended Battery | 22.2V4000mAh-5000mAh 45c |
| Battery Connector | EC5 |
| Aileron | Yes |
| Rudder | Yes |
| Flaps | Yes |
| Retracts | Yes |
| Approx. Flying Duration | 3minutes |
| Minimum Age Recommendation | 14+ |
| Experience Level | Intermediate |
| Assembly Time | 5 minutes |
| Wing Load | 85.2 g/dm² ( 0.17oz/in²) |
| Wing Area | 38.5 dm² ( 596.6 sq.in) |
Videos
Parts
FMS Reflex V3 Stable Flight Controller
Common Parts - 100A ESC With 300 Input Cable EC5
80mm Rafale Fuselage
80mm Rafale Main Wing Set
80mm Rafale Vertical Stabilizer
80mm Rafale Canard
